General characteristics

HAM bands
?
Frequency stability
?
Tuning steps
?
Memories
?

Receiver

RX-range
15/40/80 m (lower 250 KHz on each band)
Modulations
CW
Sensitivity
?
Selectivity
?
Filters
?
Receiver system
XTAL TX. VFO option
IF-frequencies
?
Image rejection
?
Audio output
?

Transmitter

TX-range
15/40/80 m (lower 250 KHz on each band)
Modulations
CW
RF-output
90 W (input)

Connections

Antenna
-
Impedance
50 Ω
Other
-

Electrical

Power requirements
Mains
Current drain RX
?
TX
?

Physical

Dimensions (w×h×d)
?
Weight
?
Form factor
Unknown
Manufactured
Between 1967 and 1976

Other features

Usage
Amateur / Ham radio operators
Features + options
-
Accessories
-
RigReference ID
2921
MPN
HEATHKIT-HW-000016

Manuals, diagrams and brochures

No documents available for this particular model.

Upload relevant documents

Reviews & stories

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Heathkit HW-16. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the Heathkit HW-16 is around:

  • USD 8.00 ~ USD 19.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2010 USD 49.88 Used / Okay athena60_98
2004 USD 80.00 Used / Good ZedderBRL
1971 USD 99.95 New / Mint K9EQ
