General characteristics

HAM bands
2m
Frequency stability
?
Tuning steps
6 XTAL channels for Rx and Tx
Memories
6 channels in bank(s)

Receiver

RX-range
143.9-148.3 MHz
Modulations
FM
Sensitivity
?
Selectivity
?
Filters
?
Receiver system
Double conversion superheterodyne, XTAL
IF-frequencies
10.7 MHz / 455 kHz
Image rejection
?
Audio output
2 W

Transmitter

TX-range
143.9-148.3 MHz
Modulations
FM
RF-output
10 W

Connections

Antenna
SO-239
Impedance
50Ω
Other
-

Electrical

Power requirements
12.6-16 V DC
Current drain RX
?
TX
?

Physical

Dimensions (w×h×d)
210 × 70 × 251 mm (8.27 × 2.76 × 9.88 in)
Weight
4.50 kg (9.9 lbs)
Form factor
Mobile
Manufactured
Between 1973 and 197x in USA

Other features

Usage
Amateur / Ham radio operators
Features + options
Tone burst encoder optional
Accessories
-
RigReference ID
2924
MPN
HEATHKIT-HW-000202
