General characteristics

HAM bands
2m  70cm
Frequency stability
?
Tuning steps
?
Memories
162 channels in 1 bank(s)

Receiver

RX-range
118-174 / 400-479 MHz
Modulations
AM   FM
Sensitivity
0.18 µV (12 dB SINAD)
Selectivity
12 kHz (-6 dB)
30 kHz (-60 dB)
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
Better than 60 dB
Audio output
?

Transmitter

TX-range
144-146 / 430-440 MHz (Europe)
Modulations
FM
RF-output
High: 50/35 W, Mid hi: 20/20 W, Mid lo: 10/10 W, Low: 5/5 W

Connections

Antenna
SO-239
Impedance
50 Ω
Other
-

Electrical

Power requirements
13.8V DC
Current drain RX
0.8-1 A
TX
Max 12 A

Physical

Dimensions (w×h×d)
140 × 40 × 185 mm (5.51 × 1.57 × 7.28 in)
Weight
1.17 kg (2.6 lbs)
Form factor
Mobile
Manufactured
Between 19xx and 19xx

Other features

Usage
Amateur / Ham radio operators
Features + options
CTCSS. 9K6 packet ready.
Accessories
-
RigReference ID
2979
MPN
ICOM-IC-000207H

Manuals, diagrams and brochures

ICOM IC-207H Instruction Manual.pdf PDF - Unknown size, submitted by RigReference

Upload relevant documents

Reviews & stories

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used ICOM IC-207H. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the ICOM IC-207H is around:

  • USD 52.00 ~ USD 49.00
  • CAD 149.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2018 CAD 150.00 Used / Mint Gary Hessler
2018 CAD 150.00 Used / Mint Gary Hessler
2010 USD 125.00 Used / Mint Cliff Fox
2009 USD 165.00 Used / Good AC8HV
