New price 1975 in the US: $489.00

Frequency range

RX-range
146-148 MHz
TX-range
146-148 MHz
HAM bands
2m
Stability
?
Tuning steps
30 kHz kHz
Filters
?

Receiver

Modulations
FM
Sensitivity
0.4 µV or better
Selectivity
?
Receiver system
?
IF-frequencies
?
Image rejection
?
Audio output
?

Transmitter

Modulations
FM
RF-Output
High: 10 W, Low: 1 W

Connections

Antenna
SO-239
Impedance
50Ω

Electrical

Power requirements
13.8V DC
Current drain RX
?
TX
2.5 A max

Physical

Dimensions (w×h×d)
?
Weight
?
Form factor
Mobile
Manufactured
Between 1973 and 197x in Japan
MPN
ICOM-IC-000230

Other features

Memories
67 channels in 1 bank(s)
Usage
Amateur / Ham radio operators
Features + options
?
Accessories
?

Manuals, diagrams and brochures

ICOM IC-230 Instruction manual submitted by RigReference
