General characteristics

HAM bands
160m  80m  40m  30m (WARC)  20m  17m (WARC)  15m  12m (WARC)  10m
Frequency stability
?
Tuning steps
?
Memories
?

Receiver

RX-range
0.1-30 MHz
Modulations
AM   FM   CW   SSB
Sensitivity
?
Selectivity
?
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
?
Audio output
?

Transmitter

TX-range
10-160 m + WARC
Modulations
AM   FM   CW   SSB
RF-output
10-100 W (AM 10-40 W)

Connections

Antenna
SO-239
Impedance
50 Ω
Other
-

Electrical

Power requirements
13.8V DC
Current drain RX
1.2-1.5 A
TX
Max 20 A

Physical

Dimensions (w×h×d)
241 × 94 × 272 mm (9.49 × 3.70 × 10.71 in)
Weight
5.00 kg (11.0 lbs)
Form factor
Base Station
Manufactured
Between 1985 and 198x in Japan

Other features

Usage
Amateur / Ham radio operators
Features + options
-
Accessories
-
RigReference ID
3144
MPN
ICOM-IC-000731
