General characteristics

HAM bands
160m  80m  60m  40m  30m (WARC)  20m  17m (WARC)  15m  12m (WARC)  11m (CB)  6m  2m  1.25m  70cm  33cm  23cm  10m  4m  2000m
Frequency stability
?
Tuning steps
?
Memories
1000 channels in 1 bank(s)

Receiver

RX-range
0.1-1999.8 MHz
Modulations
AM   FM   W-FM   CW   SSB   FSK
Sensitivity
AM (10 dB S/N)
0.1-5 MHz: 3.2 µV
0.5-1.8 MHz: 6.3 µV
1.8-30 MHz: 1 µV
30-1000 MHz: 1.4 µV
1000-1240 MHz: 4 µV
1240-1300 MHz: 2 µV
1300-1600 MHz: 4 µV
1600-2000 MHz: 5.6 µV
FM (12 dB SINAD)
30-1000 MHz: 0.5 µV
1000-1240 MHz: 1 µV
1240-1300 MHz: 0.5 µV
1300-1600 MHz: 1 µV
1600-2000 MHz: 1.4 µV
W-FM (12 dB SINAD)
30-1000 MHz: 1.4 µV
1000-1240 MHz: 4 µV
1240-1300 MHz: 2 µV
1300-1600 MHz: 4 µV
1600-2000 MHz: 5.6 µV
SSB/CW/FSK (10 dB S/N)
0.1-0.5 MHz: 0.5 µV
0.5-1.8 MHz: 1 µV
1.8-30 MHz: 0.16 µV
30-1000 MHz: 0.32 µV
1000-1240 MHz: 0.63 µV
1240-1300 MHz: 0.32 µV
1300-1600 MHz: 0.63 µV
1600-2000 MHz: 1 µV
Selectivity
AM
6 kHz (-6 dB)
FM
15 kHz (-6 dB)
W-FM
150 kHz (-6 dB)
SSB/CW/FSK
2.4 kHz (-6 dB)
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
?
Audio output
Internal speaker

Connections

Antenna
N-type + RCA (Tulip)
Impedance
50Ω
Other
-

Electrical

Power requirements
Mains or 13.8V DC
Current drain RX
?
TX
-

Physical

Dimensions (w×h×d)
424 × 150 × 365 mm (16.69 × 5.91 × 14.37 in)
Weight
20.00 kg (44.1 lbs)
Form factor
Base Station
Manufactured
Between 1999 and 200x in Japan

Other features

Usage
Amateur / Ham radio operators
Features + options
Same as model E, but with color LCD instead.
Accessories
-
RigReference ID
3229
MPN
ICOM-IC-R009000L

Manuals, diagrams and brochures

No documents available for this particular model.

Upload relevant documents

Reviews & stories

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used ICOM IC-R9000L. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the ICOM IC-R9000L is around:

  • USD 481.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2010 USD 2999.00 Used / Mint eBay
