The ICOM IC-S22 is similar but operates on the 2 meter band.
General characteristics
- HAM bands
- 70cm
- Frequency stability
- ± 10 p.p.m. (0-50 °C)
- Tuning steps
- ?
- Memories
- 47 channels in 1 bank(s)
Receiver
- RX-range
- 430-440 MHz
- Modulations
- FM
- Sensitivity
- -16 dBµ (12 dB SINAD)
- Selectivity
- 15 kHz (-6 dB)
30 kHz (-60 dB) - Filters
- ?
- Receiver system
- Double conversion superheterodyne
- IF-frequencies
- 1st: 30.85 MHz
2nd: 450 kHz - Image rejection
- ?
- Audio output
- 200 mW
Transmitter
- TX-range
- 430-440 MHz
- Modulations
- FM
- RF-output
- 0.5/5 W
Connections
- Antenna
- SMA
- Impedance
- 50Ω
- Other
- -
Electrical
- Power requirements
- 4.5-16 V DC
- Current drain RX
- ?
- TX
- ?
Physical
- Dimensions (w×h×d)
- 57 × 110 × 27 mm (2.24 × 4.33 × 1.06 in) excluding projections
- Weight
- 270 gr (9.5 oz)
- Form factor
- Handheld
- Manufactured
- Between 19xx and 20xx in Japan
Other features
- Usage
- Amateur / Ham radio operators
- Features + options
- -
- Accessories
- -
- RigReference ID
- 3234
- MPN
- ICOM-IC-S000032
