General characteristics

HAM bands
2m
Frequency stability
± 10 p.p.m. +14°F to +140°F. (-10°C to +60°C)
Tuning steps
?
Memories
107 channels in 1 bank(s)

Receiver

RX-range
136-174 MHz
Modulations
FM   AFSK
Sensitivity
0.16 µV (typical for 12 dB SINAD)
Selectivity
65 dB typical
Filters
?
Receiver system
Double conversion superheterodyne
IF-frequencies
1st: 21.7 MHz
2nd: 450 kHz
Image rejection
75 dB typical
Audio output
300 mW (typical with an 8 ohm load)

Transmitter

TX-range
144-148 MHz
Modulations
FM   AFSK
RF-output
0.5 / 5.5 W

Connections

Antenna
BNC
Impedance
50Ω
Other
-

Electrical

Power requirements
7.2 V DC
Current drain RX
20-250 mA
TX
0.7-2 A

Physical

Dimensions (w×h×d)
54 × 132 × 35 mm (2.13 × 5.20 × 1.38 in)
Weight
350 gr (12.4 oz) with antenna and battery
Form factor
Handheld
Manufactured
Between 2001 and 200x in Japan

Other features

Usage
Amateur / Ham radio operators
Features + options
CTCSS & DCS. Alpha tags.
Accessories
-
RigReference ID
3256
MPN
ICOM-IC-V000008

Manuals, diagrams and brochures

ICOM IC-V8 Instruction Manual.pdf PDF - Unknown size, submitted by RigReference

Upload relevant documents

Reviews & stories

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used ICOM IC-V8. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the ICOM IC-V8 is around:

  • USD 12.00 ~ USD 20.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2004 USD 189.00 New / Good drguyor
2001 USD 189.95 New / Mint K4XXX
