General characteristics

HAM bands
2m  70cm
Frequency stability
?
Tuning steps
5 / 10 / 12.5 / 15 / 20 / 25 / 30 / 50 kHz
Memories
100 channels in 1 bank(s)

Receiver

RX-range
136-174 / 400-470 MHz
Modulations
FM
Sensitivity
0.18 µV (12 dB SINAD)
Selectivity
15 kHz (-6 dB), 30 kHz (-60 dB)
Filters
?
Receiver system
Double conversion superheterodyne
IF-frequencies
1st: 43.1 MHz (VHF), 35.8 MHz (UHF)
2nd: 455 KHz
Image rejection
>50 dB
Audio output
?

Transmitter

TX-range
144-146 / 430-440 MHz
Modulations
FM
RF-output
High: 5/5 W, Medium: 0.5/0.5 W, Low: 15/15 mW

Connections

Antenna
BNC
Impedance
50 Ω
Other
-

Electrical

Power requirements
4.8-9.6V DC with battery pack or 4.5-16V DC external
Current drain RX
30-210 mA
TX
Max 1.5 A

Physical

Dimensions (w×h×d)
57 × 125 × 31 mm (2.24 × 4.92 × 1.22 in)
Weight
320 gr (11.3 oz) with BP-170
Form factor
Handheld
Manufactured
Between 1995 and 199x in Japan

Other features

Usage
Amateur / Ham radio operators
Features + options
CTCSS on TX (RX option UT-94), DTMF. Twin RX
Accessories
-
RigReference ID
3266
MPN
ICOM-IC-W000031E
