General characteristics

HAM bands
160m  80m  40m  20m  15m  10m
Frequency stability
?
Tuning steps
?
Memories
11 channels in 1 bank(s)

Receiver

RX-range
10-160 m
Modulations
AM   FM   CW   SSB   RTTY
Sensitivity
?
Selectivity
?
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
?
Audio output
?

Transmitter

TX-range
10-160 m
Modulations
AM   FM   CW   SSB   RTTY
RF-output
10 W

Connections

Antenna
SO-239
Impedance
50 Ω
Other
-

Electrical

Power requirements
13.8V DC
Current drain RX
?
TX
?

Physical

Dimensions (w×h×d)
348 × 145 × 347 mm (13.70 × 5.71 × 13.66 in) including protrusions
Weight
10.00 kg (22.1 lbs)
Form factor
Base Station
Manufactured
Between 1983 and 19xx in Japan

Other features

Usage
Amateur / Ham radio operators
Features + options
Full QSK
Accessories
-
RigReference ID
3287
MPN
JRC-JST-000100S

Manuals, diagrams and brochures

No documents available for this particular model.

Upload relevant documents

Reviews & stories

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used JRC JST-100S. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

These estimates are based on the following prices:

Year Historic price Condition Submitted by
