Kenwood TM-231E

Mobile VHF Transceiver

View all reviews (0) Add a review Add to my shack



Login or Register to upload images

Find Kenwood TM-231E rigs and spare parts on eBay Find the Kenwood TM-231E on Amazon
We receive a small fee when you buy through these links, thank you!

European version of the Kenwood TM-231A.

Frequency range

RX-range
144-146 MHz
TX-range
144-146 MHz
HAM bands
?
Stability
?
Tuning steps
?
Filters
?

Receiver

Modulations
FM
Sensitivity
?
Selectivity
?
Receiver system
?
IF-frequencies
?
Image rejection
?
Audio output
?

Transmitter

Modulations
FM
RF-Output
High: 50 W, Medium: 10 W, Low: 2 W

Connections

Antenna
SO-239
Impedance
50 Ω

Electrical

Power requirements
11-16V DC
Current drain RX
Max 700 mA
TX
Max 11 A

Physical

Dimensions (w×h×d)
140 × 40 × 160 mm (5.51 × 1.57 × 6.30 in)
Weight
1.20 kg (2.6 lbs)
Form factor
Mobile
Manufactured
Between 1989 and 19xx
MPN
KENWOOD-TM-000231E

Other features

Memories
20 channels in 1 bank(s)
Usage
Amateur / Ham radio operators
Features + options
?
Accessories
?

Manuals, diagrams and brochures

Kenwood TM-231 / TM-331 / TM-431 / TM-531 Manual submitted by RigReference
Kenwood TM-231 Block Diagram submitted by RigReference
Kenwood TM-231 Schematic Diagram submitted by RigReference

Upload relevant documents

Show other documents.
