General characteristics

HAM bands
2m  70cm
Frequency stability
±5ppm
Tuning steps
?
Memories
200 channels in 1 bank(s)

Receiver

RX-range
118-524 / 800-1300 MHz
Modulations
AM   FM   N-FM
Sensitivity
Less than 0.16 µV (VHF/UHF)
Selectivity
-6 dB: More than 12 kHz
-40 dB: Less than 28 kHz
Filters
?
Receiver system
Double Super Heterodyne
IF-frequencies
1st: 38.85 MHz (VHF), 45.05 (UHF)
2nd: 450 kHz (VHF), 455 kHz (UHF)
Image rejection
?
Audio output
?

Transmitter

TX-range
144-146 / 430-440 MHz
Modulations
FM   N-FM
RF-output
High: 50/35 W, Medium: 10/10 W, Low: 5/5 W

Connections

Antenna
N-type
Impedance
50 Ω
Other
-

Electrical

Power requirements
13.8V DC
Current drain RX
1 A max
TX
11.5 A max

Physical

Dimensions (w×h×d)
140 × 40 × 195 mm (5.51 × 1.57 × 7.68 in) Panel: 140×60×34 mm
Weight
1.40 kg (3.1 lbs)
Form factor
Mobile
Manufactured
Between 2000 and 200x in Singapore

Other features

Usage
Amateur / Ham radio operators
Features + options
APRS
Auto repeater offset
Band scope
Built-in TNC 1K2/9K6
DTMF hand mic
DX-info
Dual display
PBBS
Packet 1200/9600 TNC
Remote head
Twin RX
Accessories
-
RigReference ID
3427
MPN
KENWOOD-TM-D000700E
