General characteristics

HAM bands
2m
Frequency stability
?
Tuning steps
?
Memories
12 channels in 1 bank(s)

Receiver

RX-range
144-146 MHz
Modulations
FM
Sensitivity
?
Selectivity
?
Filters
?
Receiver system
XTAL
IF-frequencies
?
Image rejection
?
Audio output
?

Transmitter

TX-range
144-146 MHz
Modulations
FM
RF-output
High: 2 W, Low: 0.4 W

Connections

Antenna
Built-in sweep
Impedance
50 Ω
Other
-

Electrical

Power requirements
9.6-15.6V DC
Current drain RX
45 mA
TX
Max 700 mA

Physical

Dimensions (w×h×d)
135 × 58 × 191 mm (5.31 × 2.28 × 7.52 in)
Weight
1.60 kg (3.5 lbs) 10 × NiCd and mic included
Form factor
Mobile
Manufactured
Between 1976 and 197x in Japan

Other features

Usage
Amateur / Ham radio operators
Features + options
-
Accessories
-
RigReference ID
3443
MPN
KENWOOD-TR-002200GII

Manuals, diagrams and brochures

Kenwood TR-2200 Instruction Manual PDF - Unknown size, submitted by RigReference
