Frequency range

RX-range
50-54 MHz
TX-range
50-54 MHz
HAM bands
?
Stability
?
Tuning steps
?
Filters
?

Receiver

Modulations
AM   FM   CW   USB   LSB
Sensitivity
AM: 0.7 µV (10 dB S/N)
FM: 0.2 µV (12 dB SINAD)
SSB/CW: 0.16 µV (10 dB S/N)
Selectivity
?
Receiver system
?
IF-frequencies
?
Image rejection
?
Audio output
?

Transmitter

Modulations
AM   FM   CW   USB   LSB
RF-Output
High: 10 W, Low: 1 W

Connections

Antenna
SO-239
Impedance
50 Ω

Electrical

Power requirements
13.8V DC
Current drain RX
?
TX
?

Physical

Dimensions (w×h×d)
170 × 68 × 260 mm (6.69 × 2.68 × 10.24 in)
Weight
2.40 kg (5.3 lbs)
Form factor
Mobile
Manufactured
Between 198x and 198x
MPN
KENWOOD-TR-009300

Other features

Memories
?
Usage
Amateur / Ham radio operators
Features + options
?
Accessories
?
