USA Catalog Number: 20-135

General characteristics

HAM bands
6m
Frequency stability
?
Tuning steps
5 / 12.5 / 25 kHz
Memories
200 channels in 1 bank(s) @ 8 channels/second

Receiver

RX-range
30-54 / 108-136 / 138-174 / 380-512 / 806-906 MHz (USA)
Modulations
AM   FM
Sensitivity
30-54 MHz: 1.0 µV
108-136 MHz: 2.0 µV
136-174 MHz: 1.0 µV
380-512 MHz: 1.0 µV
806-960 MHz: 2.0 µV
Selectivity
± 10 kHz @ -6 dB
± 20 kHz @ -50 dB
Filters
1 crystal filter, 1 ceramic filter
Receiver system
?
IF-frequencies
1st: 10.7 MHz
2nd: 455 kHz
Image rejection
10.7 MHz 50 dB @ 154 MHz
Audio output
200 mW nominal

Connections

Antenna
-
Impedance
50Ω
Other
-

Electrical

Power requirements
9V DC / 6 AA cells
Current drain RX
55 mA
TX
-

Physical

Dimensions (w×h×d)
165 × 69 × 46 mm (6.50 × 2.72 × 1.81 in)
Weight
400 gr (14.1 oz)
Form factor
Handheld
Manufactured
Between 19xx and 19xx

Other features

Usage
Amateur / Ham radio operators
Features + options
-
Accessories
-
RigReference ID
3887
MPN
20-135

Manuals, diagrams and brochures

Realistic PRO-34 Owners Manual PDF - Unknown size, submitted by RigReference

Upload relevant documents

Reviews & stories

Rating Title Submitted
a very good scanner 11 years ago by robs180

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used RadioShack / Realistic Pro-34. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the RadioShack / Realistic Pro-34 is around:

  • USD 4.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
1983 USD 329.95 New / Mint Cliff Fox
