General characteristics

HAM bands
6m  2m  70cm
Frequency stability
?
Tuning steps
?
Memories
400 channels in 1 bank(s)

Receiver

RX-range
50-54 / 144-146 / 430-440 MHz
Modulations
FM
Sensitivity
?
Selectivity
?
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
?
Audio output
?

Transmitter

TX-range
50-54 / 144-146 / 430-440 MHz
Modulations
FM
RF-output
High: 20/20/20 W, Low: ?/?/? W

Connections

Antenna
-
Impedance
50 Ω
Other
-

Electrical

Power requirements
13.8V DC
Current drain RX
?
TX
?

Physical

Dimensions (w×h×d)
140 × 40 × 173 mm (5.51 × 1.57 × 6.81 in)
Weight
1.20 kg (2.6 lbs)
Form factor
Mobile
Manufactured
Between 19xx and 19xx

Other features

Usage
Amateur / Ham radio operators
Features + options
9K6 packet ready. Twin RX
Accessories
-
RigReference ID
4086
MPN
STANDARD-C-005900B
