General characteristics

HAM bands
70cm
Frequency stability
?
Tuning steps
?
Memories
?

Receiver

RX-range
430-440 / 1260-1300 MHz
Modulations
FM
Sensitivity
0.16 µV (12 dB SINAD)
Selectivity
12 kHz (-6 dB), 24 kHz (-60 dB)
Filters
?
Receiver system
70 cm: Double-conversion, 23 cm: Triple-conversion superheterodyne
IF-frequencies
1st: 21.8 MHz (70 cm), 157.0 MHz (23 cm)
2nd: 455 KHz (70 cm), 45.0 MHz (23 cm)
3rd: 455 KHz (23 cm)
Image rejection
?
Audio output
?

Transmitter

TX-range
430-440 / 1260-1300 MHz
Modulations
FM
RF-output
High: 10/10 W, Low: 1/1 W

Connections

Antenna
-
Impedance
50 Ω
Other
-

Electrical

Power requirements
13.8V DC +/-15%
Current drain RX
Max 900 mA
TX
1.5-4.5 A

Physical

Dimensions (w×h×d)
155 × 55 × 207 mm (6.10 × 2.17 × 8.15 in)
Weight
1.80 kg (4.0 lbs)
Form factor
Mobile
Manufactured
Between 1986 and 198x in Japan

Other features

Usage
Amateur / Ham radio operators
Features + options
Twin RX
Accessories
-
RigReference ID
4088
MPN
STANDARD-C-006000

Manuals, diagrams and brochures

Standard C-6000 / C-6000S Manual (probably Japanese) PDF - 1.60 MB, submitted by Gerd
