General characteristics

HAM bands
80m  40m  20m  15m  10m
Frequency stability
?
Tuning steps
?
Memories
?

Receiver

RX-range
10-80 m
Modulations
CW   SSB
Sensitivity
?
Selectivity
?
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
?
Audio output
?

Transmitter

TX-range
10-80 m
Modulations
CW   SSB
RF-output
100 W

Connections

Antenna
SO-239
Impedance
50 Ω
Other
-

Electrical

Power requirements
12-14V DC
Current drain RX
?
TX
Max 20 A

Physical

Dimensions (w×h×d)
247 × 95 × 301 mm (9.72 × 3.74 × 11.85 in)
Weight
5.90 kg (13.0 lbs)
Form factor
Base Station
Manufactured
Between 1980 and 198x

Other features

Usage
Amateur / Ham radio operators
Features + options
-
Accessories
-
RigReference ID
4111
MPN
SWAN-(CUBIC)-000100-MX

Manuals, diagrams and brochures

No documents available for this particular model.

Upload relevant documents

Reviews & stories

Rating Title Submitted
Swan 100MX Great Rig 8 years ago by CRY42

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Swan (Cubic) 100 MX. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the Swan (Cubic) 100 MX is around:

  • USD 39.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2010 USD 100.00 Used / Good CRY42
