1 x 6LQ6 final. 12 VDC option

General characteristics

HAM bands
80m  40m  20m  15m  10m
Frequency stability
?
Tuning steps
?
Memories
?

Receiver

RX-range
10-80 m
3.5-4 / 7-7.3 / 14-14.35 / 21-21.45 / 28-29.7 MHz
Modulations
CW   SSB
Sensitivity
?
Selectivity
?
Filters
?
Receiver system
? conversion superheterodyne
IF-frequencies
?
Image rejection
?
Audio output
?

Transmitter

TX-range
10-80 m
3.5-4 / 7-7.3 / 14-14.35 / 21-21.45 / 28-29.7 MHz
Modulations
CW   SSB
RF-output
SSB: 260 W (PEP input), CW: 180 W (input)

Connections

Antenna
SO-239
Impedance
50/75 Ω
Other
-

Electrical

Power requirements
Mains
Current drain RX
?
TX
?

Physical

Dimensions (w×h×d)
330 × 140 × 280 mm (12.99 × 5.51 × 11.02 in)
Weight
11.00 kg (24.3 lbs)
Form factor
Unknown
Manufactured
Between 19xx and 19xx

Other features

Usage
Amateur / Ham radio operators
Features + options
-
Accessories
-
RigReference ID
4116
MPN
SWAN-(CUBIC)-000270-CYGNET

Manuals, diagrams and brochures

No documents available for this particular model.

Upload relevant documents

Reviews & stories

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Swan (Cubic) 270 Cygnet. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the Swan (Cubic) 270 Cygnet is around:

  • USD 319.00 ~ USD 200.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2020 USD 320.00 Used / Good Gerry
2019 USD 201.00 Used / Good Robert G Leach
