Same as FT-101E but with the RF-processor as an option.

General characteristics

HAM bands
160m  80m  40m  20m  15m  10m
Frequency stability
?
Tuning steps
?
Memories
?

Receiver

RX-range
10-160 m
Modulations
AM   CW   SSB
Sensitivity
0.3 µV (10 dB S/N)
Selectivity
AM/SSB/CW: 2.4 kHz (-6 dB), 4 kHz (-60 dB)
CW with optional filter: 600 Hz (-6 dB), 1.2 kHz (-60 dB)
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
?
Audio output
?

Transmitter

TX-range
10-160 m
Modulations
AM   CW   SSB
RF-output
100 W

Connections

Antenna
SO-239
Impedance
50/75 Ω
Other
-

Electrical

Power requirements
12V DC or mains
Current drain RX
600 mA
TX
Max 21 A

Physical

Dimensions (w×h×d)
?
Weight
?
Form factor
Base Station
Manufactured
Between 197x and 19xx in Japan

Other features

Usage
Amateur / Ham radio operators
Features + options
-
Accessories
-
RigReference ID
4235
MPN
YAESU-FT-000101EE

Manuals, diagrams and brochures

No documents available for this particular model.

Upload relevant documents

Reviews & stories

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Yaesu FT-101EE. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the Yaesu FT-101EE is around:

  • USD 348.00 ~ USD 121.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2018 USD 350.00 Used / Good Ivan Taylor
2012 USD 200.00 Used / Good KK4IBG
1977 USD 649.00 New / Mint Marc
