General characteristics

HAM bands
?
Frequency stability
?
Tuning steps
?

Receiver

RX-range
144-146 MHz (Europe)
144-148 MHz (USA)
Modulations
FM   CW   SSB
Sensitivity
?
Selectivity
?
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
?
Audio output
?

Transmitter

TX-range
144-146 MHz (Europe)
144-148 MHz (USA)
Modulations
FM   CW   SSB
RF-Output
High: 2.5 W, Low: 0.5 W

Connections

Antenna
SO-239
Impedance
50 Ω
Other
-

Electrical

Power requirements
8.5-15.2V DC
Current drain RX
70 mA
TX
Max 800 mA

Physical

Manufactured
Between 1981 and 198x in Japan
Dimensions (w×h×d)
150 × 58 × 195 mm (5.91 × 2.28 × 7.68 in)
Weight
1.30 kg (2.9 lbs) without batteries
Form factor
Mobile

Other features

Memories
10 channels in 1 bank(s)
Usage
Amateur / Ham radio operators
Features + options
?
Accessories
?
MPN
YAESU-FT-000290R
