The Yaesu FT-7200 is similar to the Yaesu FT-2200 but covers the 430-450 MHz (70 cm) band instead of 2 meters. RF power output is 5, 20 or 35 watts.

General characteristics

HAM bands
?
Frequency stability
?
Tuning steps
5 / 10 / 12.5 / 15 / 20 / 25 / 50 kHz

Receiver

RX-range
430-440 MHz (Europe)
430-450 MHz (USA)
Modulations
FM
Sensitivity
?
Selectivity
?
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
?
Audio output
?

Transmitter

TX-range
430-440 MHz (Europe)
430-450 MHz (USA)
Modulations
FM
RF-Output
High: 35 W, Medium: 20 W, Low: 5 W

Connections

Antenna
N-type
Impedance
50 Ω
Other
-

Electrical

Power requirements
13.8V DC
Current drain RX
Max 0.7 A
TX
Max 10 A

Physical

Manufactured
Between 1994 and 19xx
Dimensions (w×h×d)
140 × 40 × 160 mm (5.51 × 1.57 × 6.30 in)
Weight
1.25 kg (2.8 lbs)
Form factor
Mobile

Other features

Memories
?
Usage
Amateur / Ham radio operators
Features + options
?
Accessories
?
MPN
YAESU-FT-007200
