General characteristics

HAM bands
80m  40m  20m  15m  10m
Frequency stability
?
Tuning steps
?
Memories
?

Receiver

RX-range
10-80 m
Modulations
AM   CW   SSB
Sensitivity
0.25 µV (10 dB S/N)
Selectivity
2.4 kHz (-6 dB), 4 kHz (-60 dB)
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
10 m: >50 dB 15-80 m: >60 dB
Audio output
?

Transmitter

TX-range
10-80 m
Modulations
AM   CW   SSB
RF-output
AM: 12 W, SSB/CW: 50 W

Connections

Antenna
SO-239
Impedance
50 Ω
Other
-

Electrical

Power requirements
13.5V DC +/-10%
Current drain RX
Max 600 mA
TX
Max 10 A

Physical

Dimensions (w×h×d)
230 × 80 × 320 mm (9.06 × 3.15 × 12.60 in)
Weight
5.50 kg (12.1 lbs)
Form factor
Mobile
Manufactured
Between 197x and 19xx in Japan

Other features

Usage
Amateur / Ham radio operators
Features + options
-
Accessories
-
RigReference ID
4350
MPN
YAESU-FT-000007B

Manuals, diagrams and brochures

Yaesu FT-7b Instruction Manual PDF - Unknown size, submitted by RigReference
Yaesu FT-7b Schematic Diagram PDF - Unknown size, submitted by RigReference

Upload relevant documents

Reviews & stories

Rating Title Submitted
My first hf rig 13 years ago by m6mjrtobe

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Yaesu FT-7B. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the Yaesu FT-7B is around:

  • GBP 25.00 ~ GBP 6.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2011 GBP 129.00 Used / Good m6mjrtobe
2008 GBP 65.00 Used / Okay ledtoe
