General characteristics

HAM bands
?
Frequency stability
10 ppm (0 to 60 C)
Tuning steps
0.001 kHz
Memories
?

Receiver

RX-range
9 kHz - 30 MHz
Modulations
AM   N-AM   AM-sync   FM   N-FM   W-FM   CW   USB   LSB
Sensitivity
Mode 0.009-0.1 MHz 0.1-2 MHz 2-30 MHz
AM 9.0V 2.2V 0.9V
LSB, USB 3.0V 0.7V 0.3V
CW 1.2V 0.2V 0.1V
FM3, FM6, FMN 2.2V 0.4V 0.2V
Selectivity
AM 6 kHz
AMN 4 kHz
AMS 4 kHz
LSB, USB 2.5 kHz
CW 500 Hz
FM3 3 kHz
FM6 6 kHz
FMN 12 kHz
Filters
?
Receiver system
DDS-based double-conversion superheterodyne with software-defined last IF stage and demodulator
IF-frequencies
1st: 45 MHz
2nd: 12 kHz
Image rejection
60 dB
Audio output
?

Connections

Antenna
SMA
Impedance
50Ω
Other
-

Electrical

Power requirements
Drawn from ISA-bus
Current drain RX
?
TX
-

Physical

Dimensions (w×h×d)
195 × 99 × 19 mm (7.68 × 3.90 × 0.75 in)
Weight
310 gr (10.9 oz)
Form factor
PC-card
Manufactured
Between 200x and 200x

Other features

Usage
Amateur / Ham radio operators
Features + options
DSP
Trunking option
12 kHz IF2 output
Number of memory channels limited by computer memory
Accessories
-
RigReference ID
4423
MPN
WINRADIO-WR-G000303I
