Professional shortwave receiver
Controller via USB interface

General characteristics

HAM bands
160m  80m  60m  40m  30m (WARC)  20m  17m (WARC)  15m  12m (WARC)  11m (CB)  10m  2000m
Frequency stability
0.5 ppm (0 to 60 C)
Tuning steps
1 ppm (25C 2C) kHz
Memories
?

Receiver

RX-range
9 kHz - 30 MHz (9 kHz - 180 MHz optional)
Modulations
AM   AM-sync   FM   CW   USB   LSB   DSB   ISB
Sensitivity
Mode 0.15?0.5 MHz 0.5?1.5 MHz 1.5?30 MHz
AM, AMS (30% modulation) ?103dBm
(1.6V) ?106dBm
(1.1V) ?108dBm
(0.9V)
AM, AMS (80% modulation) ?111dBm
(0.63V) ?115dBm
(0.4V) ?116dBm
(0.35V)
LSB, USB, ISB, DSB ?115dBm
(0.40V) ?118dBm
(0.28V) ?119dBm
(0.25V)
CW ?122dBm
(0.18V) ?125dBm
(0.13V) ?130dBm
(0.07V)
FM ?110dBm
(0.7V) ?113dBm
(0.5V) ?117dBm
(0.32V)
Selectivity
?
Filters
?
Receiver system
DSP-based SDR with DDS-based double-conversion superheterodyne front end
IF-frequencies
1st: 45 MHz
2nd: 16 (12-22) kHz
Image rejection
1.8-7.3 MHz: 80 dB7.3-30 MHz: 70 dB
Audio output
600 ohm line audio

Connections

Antenna
SMA
Impedance
50Ω
Other
-

Electrical

Power requirements
?
Current drain RX
?
TX
-

Physical

Dimensions (w×h×d)
195 × 99 × 19 mm (7.68 × 3.90 × 0.75 in)
Weight
330 gr (11.6 oz)
Form factor
Headless
Manufactured
Between 200x and 200x

Other features

Usage
Amateur / Ham radio operators
Features + options
DSP
Number of memory channels limited by computer memory
Accessories
-
RigReference ID
4426
MPN
WINRADIO-WR-G000313E

Manuals, diagrams and brochures

No documents available for this particular model.

Upload relevant documents

Reviews & stories

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used WiNRADiO WR-G313e. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the WiNRADiO WR-G313e is around:

  • USD 198.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2015 USD 400.00 Used / Mint dxace1
