The Panasonic RF-2200 receives the AM, FM and shortwave bands. Ranges: .525-16.1, 3.9-8, 8-12, 12-16, 20-24 and 24-28 MHz plus FM. This radio features a very accurate analog dial. It has an S-Meter, BFO, FM AFC, Bass, Treble, Record Jack, Two Tuning Rates, Dial Lamp, Dial Lamp Switch, RF Gain, Calibrator 125/500 kHz and External Antenna Terminals. This dual conversion circuit features wide and narrow selectivity (5/3.4 kHz -6dB). The rotatable ferrite rod antenna makes the RF2200 a strong medium wave performer. Early production models where gray (as image above), later models where black.
The European counterpart is called the National / Panasonic DR-22.

Frequency range

RX-range
0.525-1.61 / 3.9-28 / 87.5-108 MHz
TX-range
-
HAM bands
-
Stability
-
Tuning steps
-
Filters
-

Receiver

Modulations
AM   FM   CW   SSB
Sensitivity
FM: 2µV
MW: 14µV
SW: 0.5µV
Selectivity
-
Receiver system
Double Superheterodyne
IF-frequencies
FM: 10.7 MHz
MW/SW 1st: 1.985 MHz
SW 2nd: 455 kHz
Image rejection
-
Audio output
3W max, 8 ohm

Transmitter

Modulations
-
RF-Output
-

Connections

Antenna
Built-in ferrite bar + Built-in telescopic
Impedance
-

Electrical

Power requirements
Mains or 4LR20 / D
Current drain RX
7W
TX
-

Physical

Dimensions (w×h×d)
305 × 200 × 100 mm (12.01 × 7.87 × 3.94 in)
Weight
3.40 kg (7.5 lbs) without batteries
Form factor
Handheld
Manufactured
Between 1978 and 1979 in Japan
MPN

Other features

Memories
-
Usage
Amateur / Ham radio operators
Features + options
-
Accessories
-

Manuals, diagrams and brochures

No documents available for this particular model.

Upload relevant documents

Show other documents.

Stories & reviews

Panasonic RF 2200 used I traded a friend months ago

National / Panasonic RF-2200, Handheld HF/VHF Receiver

I obtained an RF 2200 Panasonic radio from a friend and despite the age and lack of a strap (I made one out of old items that is better than the original one rather than pay for a used one) This is one of the best AM,FM,SW, radio I have ever listened to and is still on frequency with a slight bit of alignment I decided it needed! An excellent receiver I must say! Many happy hours of use and I only got it a few months ago SW is not quiet as accurate as a digital but I prefer to use a non digital as its what I had before (included home brew) Thanks National Panasonic Renegade

Overall

Performance
Build quality
Features
User friendlyness
Value for money
Aquired
Mint condition in 2018

What is it worth?

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the current value of the National / Panasonic RF-2200. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's value of the National / Panasonic RF-2200 might be around:

  • AUD 121.00
Price Condition Year User
AUD 135.00 Used / Okay 2014 Rahob
