The Sommerkamp TS-727GT is a handheld transceiver. The frequency range for both reception and transmission is 26.5-29.7 MHz. Frequency stability is 0.005%. Tuning steps are channelized. RF output is 0.5 W (3 W). Audio output is 0.4 W @ 10% THD. The radio features 1 memory bank with 6 channels. Current drain in receive mode is 100 mA and 180 mA in transmit mode. Dimensions are 35 × 121 × 160 mm without protrusions. Weight is 1.12 kg.
General characteristics
- HAM bands
- 11m (CB)
- Frequency stability
- 0.005%
- Tuning steps
- Channelized
- Memories
- 6 channels in 1 bank(s)
Receiver
- RX-range
- 26.5-29.7 MHz
- Modulations
- AM
- Sensitivity
- 1 µV for 10 dB S/N
- Selectivity
- 10 kHz @ -30 dB
- Filters
- ?
- Receiver system
- ?
- IF-frequencies
- ?
- Image rejection
- 11-16 V DC negative ground
- Audio output
- 0.4 W @ 10% THD
Transmitter
- TX-range
- 26.5-29.7 MHz
- Modulations
- AM
- RF-output
- 0.5 W (3 W)
Connections
- Antenna
- SO-239
- Impedance
- 50-52Ω
- Other
- -
Electrical
- Power requirements
- ?
- Current drain RX
- 100 mA
- TX
- 180 mA
Physical
- Dimensions (w×h×d)
- 121 × 35 × 160 mm (4.76 × 1.38 × 6.30 in) without protrusions
- Weight
- 1.12 kg (2.5 lbs)
- Form factor
- Handheld
- Manufactured
- Between 198x and 198x in Japan
Other features
- Usage
- Citizen Band (27Mc)
- Features + options
- -
- Accessories
- -
- RigReference ID
- 4937
- MPN
- SOMMERKAMP-TS-000727GT
Manuals, diagrams and brochures
- Sommerkamp TS-727G Instruction Manual PDF - 1.09 MB, submitted by Gerd
- Upload relevant documents
