General characteristics

HAM bands
11m (CB)
Frequency stability
0.005%
Tuning steps
Channelized
Memories
6 channels in 1 bank(s)

Receiver

RX-range
26.5-29.7 MHz
Modulations
AM
Sensitivity
1 µV for 10 dB S/N
Selectivity
10 kHz @ -30 dB
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
11-16 V DC negative ground
Audio output
0.4 W @ 10% THD

Transmitter

TX-range
26.5-29.7 MHz
Modulations
AM
RF-output
0.5 W (3 W)

Connections

Antenna
SO-239
Impedance
50-52Ω
Other
-

Electrical

Power requirements
?
Current drain RX
100 mA
TX
180 mA

Physical

Dimensions (w×h×d)
121 × 35 × 160 mm (4.76 × 1.38 × 6.30 in) without protrusions
Weight
1.12 kg (2.5 lbs)
Form factor
Handheld
Manufactured
Between 198x and 198x in Japan

Other features

Usage
Citizen Band (27Mc)
Features + options
-
Accessories
-
RigReference ID
4937
MPN
SOMMERKAMP-TS-000727GT

Manuals, diagrams and brochures

Sommerkamp TS-727G Instruction Manual PDF - 1.09 MB, submitted by Gerd
