The band coverage was wider than strictly the ham bands. Each band covered 1 MHz, with (per the manual) "Generous coverage outside the ham bands". Actual coverage was:
3.5-4.5 MHz
6.5-7.5 MHz
13.5-14.5 MHz
20.5-21.5 MHz
27.5-30.5 MHz
An optional 160 m kit could also be fitted plus there was the capability of adding a 1 MHz range anywhere in the HF range.
General characteristics
- HAM bands
- 160m 80m 40m 20m 15m 10m
- Frequency stability
- ?
- Tuning steps
- Continuous
- Memories
- None
Transmitter
- TX-range
- 80-10 m / 160 m optional
- Modulations
- AM CW SSB DSB FSK RTTY
- RF-output
- 100 W (180 W INPUT)
Connections
- Antenna
- SO-239
- Impedance
- 50Ω
- Other
- -
Electrical
- Power requirements
- Mains
- Current drain RX
- -
- TX
- ?
Physical
- Dimensions (w×h×d)
- 457 × 222 × 381 mm (17.99 × 8.74 × 15.00 in)
- Weight
- 40.80 kg (90.0 lbs)
- Form factor
- Base Station
- Manufactured
- Between 1958 and 196x
Other features
- Usage
- Amateur / Ham radio operators
- Features + options
- -
- Accessories
- -
- RigReference ID
- 5053
- MPN
- CENTRAL-ELECTRONICS-000100V
Manuals, diagrams and brochures
- Central Electronics-100V HF Transmitter Service Manual PDF - 7.46 MB, submitted by Berend
- Upload relevant documents
New and second-hand prices
Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Central Electronics 100V. Just bought or sold this model? Let us know what you traded it for and help other ham operators!
Based on historic price data, today's estimated value of the Central Electronics 100V in Good condition is around:
- USD 55
These estimates are based on the following prices:
