Uniden-Bearcat UBC245XLT

Handheld VHF/UHF Scanner / receiver

Specs Manuals (0) Reviews (0) Prices (0) Compare

Front view (Courtesy of www.discriminator.nl) - Submitted by elmer

The Uniden UBC245XLT is similar to the Uniden-Bearcat BC245XLT, but differs on some points:
- limited coverage on VHF (66-88 MHz against 29-54 MHz)
- 12.5 kHz steps on VHF (137-174 MHz)
- continuous 800 MHz band, 12.5 kHz steps

The only features making this receiver stand out is the Trunk Tracking capability and PC programmability. This receiver is not CE approved for Europe.

General characteristics

HAM bands: 6m
Frequency stability: ?
Tuning steps: 5 / 12.5 kHz
Memories: 300 channels in 10 bank(s) @ 100 channels/second

Receiver

RX-range: 66-88 / 108-174 / 406-512 / 806-956 MHz
Modulations: AM FM
Sensitivity: ?
Selectivity: ?
Filters: ?
Receiver system: ?
IF-frequencies: ?
Image rejection: ?
Audio output: 210 mW

Connections

Antenna: BNC
Impedance: 50 Ω
Other: -

Electrical

Power requirements: 4.8-6V DC battery, 12V DC external
Current drain RX: ?
TX: -

Physical

Dimensions (w×h×d): 64 × 165 × 45 mm (2.52 × 6.50 × 1.77 in)
Weight: 357 gr (12.6 oz)
Form factor: Handheld
Manufactured: Between 20xx and 20xx

Other features

Usage: Amateur / Ham radio operators
Features + options: Tracks Motorola Type I, Type II Hybrid, SMARTNET, PRIVACY PLUS and EDACS
Turbo Search (300 steps per second)
PC programmable (RS-232)
Accessories: -
RigReference ID: 5125
MPN: UNIDEN-BEARCAT-UBC000245XLT
