Similar to Alinco DR-06T except for frequency range and available options.

General characteristics

HAM bands
10m
Frequency stability
± 7 ppm
Tuning steps
5 / 8.33 / 10 / 12.5 / 15 / 20 / 25 / 30 / 50 kHz

Receiver

RX-range
28-29.695 MHz
Modulations
FM   N-FM
Sensitivity
0.25 µV (12 dB SINAD)
Selectivity
FM: 12 kHz (-6 dB), 28 kHz (-60 dB)
N-FM: 6 kHz (-6 dB), 16 kHz (-60 dB)
Filters
?
Receiver system
Double conversion superheterodyne
IF-frequencies
1st: 10.7 MHz
2nd: 450 KHz
Image rejection
?
Audio output
2 W into 8 ohm at 10% THD

Transmitter

TX-range
28-29.695 MHz
Modulations
FM   N-FM
RF-output
2/5/10 W

Connections

Antenna
SO-239
Impedance
50 Ω
Other
-

Electrical

Power requirements
13.8V DC ±15%
Current drain RX
400-600 mA
TX
3 A

Physical

Manufactured
Between 2007 and 200x
Dimensions (w×h×d)
142 × 40 × 174 mm (5.59 × 1.57 × 6.85 in)
Weight
1,000 gr (2.2 lbs)
Form factor
Mobile

Other features

Memories
100 channels in 1 bank(s)
Usage
Amateur / Ham radio operators
Features + options
?
Accessories
?
MPN
ALINCO-DR-000003T

Manuals, diagrams and brochures

Alinco DR-03/06 Instruction manual PDF - Unknown size, submitted by RigReference
Alinco DR-03SX Service manual PDF - Unknown size, submitted by RigReference
