General characteristics

HAM bands
2m  70cm
Frequency stability
?
Tuning steps
12.5 / 20 / 25 kHz
Memories
255 channels in 1 bank(s)

Receiver

RX-range
29.7-42 MHz
35-50 MHz
136-174 MHz
403-470 MHz
Modulations
FM
Sensitivity
?
Selectivity
?
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
?
Audio output
?

Transmitter

TX-range
29.7-42 MHz
35-50 MHz
136-174 MHz
403-470 MHz
Modulations
FM
RF-output
1-5 W max

Connections

Antenna
SMA
Impedance
50Ω
Other
-

Electrical

Power requirements
1400 mAh Li-Ion
Current drain RX
?
TX
?

Physical

Dimensions (w×h×d)
58 × 137 × 38 mm (2.28 × 5.39 × 1.50 in) with standard hi-capacity NimH battery
Weight
428 gr (15.1 oz) with standard hi-capacity NimH battery
Form factor
Handheld
Manufactured
Between 199x and 200x

Other features

Usage
Commercial / Land mobile communication
Features + options
CTCSS/PL and Select 5/5-tone CCIR
VOX
Full keypad
IP54
Mil spec 8110C / 810D / 810E
Accessories
-
RigReference ID
5222
MPN
MOTOROLA-GP-000380

Manuals, diagrams and brochures

No documents available for this particular model.

Upload relevant documents

Reviews & stories

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Motorola GP-380. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the Motorola GP-380 is around:

  • EUR 722.00
  • GBP 381.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2020 EUR 756.25 New / Mint RigReference
2020 GBP 399.00 New / Mint RigReference
