General characteristics

HAM bands
?
Frequency stability
?
Tuning steps
?
Memories
?

Transmitter

TX-range
15-160m
Modulations
All mode
RF-output
SSB: 1 kW PEP, CW: 850 kW (drive power: 85-100 W)

Connections

Antenna
SO-239
Impedance
50Ω
Other
-

Electrical

Power requirements
Mains
Current drain RX
?
TX
7.5 A @ 240 V AC / 15 A @ 120 V AC

Physical

Dimensions (w×h×d)
361 × 178 × 406 mm (14.21 × 7.01 × 15.98 in)
Weight
17.00 kg (37.5 lbs)
Form factor
Base Station
Manufactured
Between 197x and 198x in USA

Other features

Usage
Amateur / Ham radio operators
Features + options
-
Accessories
-
RigReference ID
5257
MPN
HEATHKIT-SB-001000

Manuals, diagrams and brochures

Heathkit SB-1000 Assembly and User Manual PDF - 2.37 MB, submitted by RigReference
