Basic Receiver - updated version

General characteristics

HAM bands
160m  80m  60m  40m  30m (WARC)  20m  17m (WARC)  15m  12m (WARC)  11m (CB)  10m
Frequency stability
?
Tuning steps
10 Hz (1 Hz optional)
Memories
None

Receiver

RX-range
0.25-30 MHz
Modulations
AM   FM   CW   SSB   ISB
Sensitivity
0.7 µV
Selectivity
?
Filters
2.7 / 16 kHz
Receiver system
Triple conversion superheterodyne
IF-frequencies
?
Image rejection
?
Audio output
Internal speaker

Connections

Antenna
BNC + Clamps / screws
Impedance
50Ω
Other
-

Electrical

Power requirements
Mains
Current drain RX
Max 80 W
TX
-

Physical

Dimensions (w×h×d)
483 × 178 × 483 mm (19.02 × 7.01 × 19.02 in) (19" rack format)
Weight
?
Form factor
Base Station
Manufactured
Between 198x and 198x in Canada

Other features

Usage
Amateur / Ham radio operators
Features + options
Remote control (via computer)
Accessories
-
RigReference ID
5281
MPN
COLLINS-HF-008050A

Manuals, diagrams and brochures

No documents available for this particular model.

Upload relevant documents

Reviews & stories

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Collins HF-8050A. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the Collins HF-8050A is around:

  • USD 41.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2010 USD 260.00 Used / Okay eBay
