General characteristics

HAM bands
160m  80m  60m  40m  30m (WARC)  20m  17m (WARC)  15m  12m (WARC)  11m (CB)  10m
Frequency stability
?
Tuning steps
?
Memories
100 channels in 1 bank(s)

Receiver

RX-range
15 kHz - 30 MHz
Modulations
AM   FM   CW   USB   LSB
Sensitivity
?
Selectivity
?
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
?
Audio output
?

Connections

Antenna
BNC
Impedance
50Ω
Other
-

Electrical

Power requirements
Mains
Current drain RX
60 W
TX
-

Physical

Dimensions (w×h×d)
483 × 133 × 450 mm (19.02 × 5.24 × 17.72 in)
Weight
14.00 kg (30.9 lbs)
Form factor
Base Station
Manufactured
Between 19xx and 19xx in Great Britain

Other features

Usage
Commercial / Land mobile communication
Features + options
-
Accessories
-
RigReference ID
5384
MPN
RACAL-RA-003791
