Note: the TC-610P is not submersible!

General characteristics

HAM bands
2m  70cm
Frequency stability
± 2.5 p.p.m.
Tuning steps
25 / 12.5 kHz
Memories
16 channels in 1 bank(s)

Receiver

RX-range
136-174 MHz
400-470 MHz
Modulations
FM
Sensitivity
≤ 0.25 µV / 0.28 µV
Selectivity
70 / 60 dB
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
?
Audio output
0.5 W

Transmitter

TX-range
136-174 MHz
400-470 MHz
Modulations
FM
RF-output
5 / 2 W

Connections

Antenna
-
Impedance
50Ω
Other
-

Electrical

Power requirements
7.4V, 1200mAh (Li-Ion Battery)
Current drain RX
?
TX
?

Physical

Dimensions (w×h×d)
119 × 55 × 33 mm (4.69 × 2.17 × 1.30 in)
Weight
270 gr (9.5 oz)
Form factor
Handheld
Manufactured
Between 201x and 201x in China

Other features

Usage
Commercial / Land mobile communication
Features + options
Water Protection Class IP66
Accessories
-
RigReference ID
5644
MPN
HYTERA-TC-000610
