General characteristics

HAM bands
2m  70cm
Frequency stability
?
Tuning steps
?
Memories
128 channels in 1 bank(s)

Receiver

RX-range
136-174 / 400-470 MHz
Modulations
FM   N-FM
Sensitivity
W-FM: 0.18 µV
FM: 0.22 µV
(12 dB SINAD)
Selectivity
8 kHz (-6 dB), 30 kHz (-60 dB)
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
?
Audio output
?

Transmitter

TX-range
136-174 / 400-470 MHz
Modulations
FM   N-FM
RF-output
VHF: 45 W, UHF: 35 W

Connections

Antenna
SO-239
Impedance
50 Ω
Other
-

Electrical

Power requirements
13.8V DC ±15%
Current drain RX
?
TX
?

Physical

Dimensions (w×h×d)
160 × 43 × 137 mm (6.30 × 1.69 × 5.39 in)
Weight
1.20 kg (2.6 lbs)
Form factor
Mobile
Manufactured
Between 201x and 201x in China

Other features

Usage
Amateur / Ham radio operators
Features + options
DTMF
CTCSS / DCS
Twin RX
Accessories
-
RigReference ID
6005
MPN
BAOJIE-BJ-UV000055

Manuals, diagrams and brochures

No documents available for this particular model.

Upload relevant documents

Reviews & stories

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Baojie BJ-UV55. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

These estimates are based on the following prices:

Year Historic price Condition Submitted by
