General characteristics

HAM bands
?
Frequency stability
?
Tuning steps
0.04-100 kHz
Memories
406 channels in 1 bank(s)

Receiver

RX-range
153-29999 kHz / 87.5-108 MHz
Modulations
AM   N-AM   W-FM   W-FM Stereo   CW   USB   LSB
Sensitivity
?
Selectivity
?
Filters
?
Receiver system
Dual conversion
IF-frequencies
?
Image rejection
?
Audio output
1.5 W

Connections

Antenna
Built-in telescopic
Impedance
50/75Ω
Other
-

Electrical

Power requirements
4 x LR6/AA or 9 V DC
Current drain RX
?
TX
-

Physical

Dimensions (w×h×d)
200 × 133 × 38 mm (7.87 × 5.24 × 1.50 in)
Weight
730 gr (1.6 lbs)
Form factor
Handheld
Manufactured
Between 2010 and 201x

Other features

Usage
Amateur / Ham radio operators
Features + options
9 / 10 kHz switch
Alpha tagging
Auto Tuning System
RF Gain Control
FM RDS/RDBS
3.2 x 1.7" LCD screen
Aux Audio Input
Accessories
-
RigReference ID
6099
MPN
SANGEAN-ATS-000909X

Manuals, diagrams and brochures

No documents available for this particular model.

Upload relevant documents

Reviews & stories

Rating Title Submitted
Sangean ATS-909X 7 years ago by jmsurprenant

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Sangean ATS-909X. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the Sangean ATS-909X is around:

  • USD 62.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2010 USD 249.95 New / Mint K9EQ
