General characteristics

HAM bands
160m  80m  60m  40m  30m (WARC)  20m  17m (WARC)  15m  12m (WARC)  11m (CB)  10m
Frequency stability
?
Tuning steps
?
Memories
50 channels in 1 bank(s)

Receiver

RX-range
0.5-30 MHz
Modulations
AM   CW   USB   LSB
Sensitivity
SSB/CW
1.605-30 MHz; ≥ 0.5 µV for 12 dB SINAD (Preamp ON)

AM
0.5-1.605 MHz; ≥ 12.6 µV for 10 dB S/N (Preamp ON)
1.605-30 MHz; ≥ 2.0 µV for 10 dB S/N (Preamp ON)
Selectivity
SSB/CW
2.1 kHz/-6 dB, 4.0 kHz/-60 dB

AM
6.0 kHz/-6 dB, 20 kHz/-60 dB
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
≥ 70 dB
Audio output
?

Transmitter

TX-range
1.605-2 / 3.5-4 / 5-8 / 9-30 MHz
Modulations
AM   CW   USB   LSB
RF-output
5-100 W (AM 5-25 W)

Connections

Antenna
SO-239
Impedance
50Ω
Other
-

Electrical

Power requirements
13.8V DC or mains
Current drain RX
1.3-2.1 A
TX
Max 20 A

Physical

Dimensions (w×h×d)
240 × 95 × 239 mm (9.45 × 3.74 × 9.41 in)
Weight
3.90 kg (8.6 lbs)
Form factor
Base Station
Manufactured
Between 19xx and 19xx in Japan

Other features

Usage
Commercial / Land mobile communication
Features + options
-
Accessories
-
RigReference ID
6126
MPN
ICOM-IC-000077

Manuals, diagrams and brochures

Icom IC-77 Instruction Manual PDF - Unknown size, submitted by RigReference

Upload relevant documents

Reviews & stories

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used ICOM IC-77. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the ICOM IC-77 is around:

  • EUR 13.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2005 EUR 100.00 Used / Fair Danie Schnetler
