Drive power: 0.06-50 mW

General characteristics

HAM bands
2m
Frequency stability
+/- 0.5 p.p.m.
Tuning steps
?

Receiver

RX-range
144-146 MHz
Modulations
All mode
Sensitivity
?
Selectivity
?
Filters
?
Receiver system
?
IF-frequencies
28-30 MHz
Image rejection
?
Audio output
?

Transmitter

TX-range
144-146 MHz
Modulations
All mode
RF-Output
25 W

Connections

Antenna
N-type
Impedance
50Ω
Other
-

Electrical

Power requirements
12-14 V DC
Current drain RX
?
TX
6 A max

Physical

Manufactured
Between 2016 and 20xx in Germany
Dimensions (w×h×d)
270 × 80 × 260 mm (10.63 × 3.15 × 10.24 in)
Weight
?
Form factor
Base Station

Other features

Memories
?
Usage
Amateur / Ham radio operators
Features + options
?
Accessories
?
MPN
KUHNE-TR-000144-PRO
