General characteristics

HAM bands
6m  2m  1.25m  70cm  33cm  23cm
Frequency stability
?
Tuning steps
3.125 / 5 / 6.25 / 7.5 / 8.33 / 10 / 12.5 / 25 kHz
Memories
1800 channels in 1 bank(s) @ 55 channels/second

Receiver

RX-range
29-54 / 108-174 / 216-512 / 764-960 / 1240-1300 MHz (cellular blocked in the US)
Modulations
AM   FM   N-FM   P25
Sensitivity
?
Selectivity
?
Filters
?
Receiver system
Triple conversion superheterodyne
IF-frequencies
1st: 380.8 MHz
2nd: 21.4 MHz
3rd: 455 kHz
Image rejection
?
Audio output
250 mW

Connections

Antenna
BNC
Impedance
50Ω
Other
-

Electrical

Power requirements
9 V DC or batteries
Current drain RX
?
TX
-

Physical

Dimensions (w×h×d)
65 × 145 × 42 mm (2.56 × 5.71 × 1.65 in)
Weight
240 gr (8.5 oz) without antenna and batteries
Form factor
Handheld
Manufactured
Between 2014 and 201x in USA

Other features

Usage
Amateur / Ham radio operators
Features + options
Trunking: Motorola I/II/III, EDACS, LTR
Spectrum sweeper
Weather channels
USB interface
CTCSS/PL
Accessories
-
RigReference ID
6429
MPN
WHISTLER-WS001040

Manuals, diagrams and brochures

Whistler WS1040 Owners Manual PDF - 2.07 MB, submitted by RigReference

Upload relevant documents

Reviews & stories

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Whistler WS1040. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the Whistler WS1040 is around:

  • USD 255.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2019 USD 256.00 New / Mint RigReference
