Same as the CRT Micron.

General characteristics

HAM bands
2m  70cm
Frequency stability
± 2.5 p.p.m.
Tuning steps
2.5 / 5 / 6.25 / 10 / 12.5 / 20 / 25 / 30 / 50 kHz
Memories
200 channels in 1 bank(s)

Receiver

RX-range
144-146 / 430-440 MHz
Modulations
FM   N-FM
Sensitivity
FM: ≤ 0.25 µV (12 dB SINAD)
N-FM: ≤ 0.35 µV (12 dB SINAD)
Selectivity
12.5 / 20 / 25 kHz
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
?
Audio output
2 W @ 8 ohm

Transmitter

TX-range
144-146 / 430-440 MHz
Modulations
FM   N-FM
RF-output
5 / 15 / 25 W

Connections

Antenna
SO-239
Impedance
50Ω
Other
-

Electrical

Power requirements
13.8 V DC ±15%
Current drain RX
?
TX
?

Physical

Dimensions (w×h×d)
124 × 39 × 163 mm (4.88 × 1.54 × 6.42 in)
Weight
640 gr (1.4 lbs)
Form factor
Mobile
Manufactured
Between 2017 and 20xx in France

Other features

Usage
Amateur / Ham radio operators
Features + options
-
Accessories
-
RigReference ID
6557
MPN
ANYTONE-AT-000778UV

Manuals, diagrams and brochures

CRT Micron User Manual PDF - 2.82 MB, submitted by Gerd

Upload relevant documents

Reviews & stories

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Anytone AT-778UV. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the Anytone AT-778UV is around:

  • EUR 123.00
  • USD 129.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2020 EUR 124.00 New / Mint eBay
2020 USD 130.00 New / Mint eBay
