General characteristics

HAM bands
2m  70cm
Frequency stability
± 5 p.p.m.
Tuning steps
2.5 / 5 / 6.25 / 10 / 12.5 / 15 / 20 / 25 / 50 kHz
Memories
809 channels in 1 bank(s)

Receiver

RX-range
88-108 / 136-174 / 350-520 MHz
Modulations
AM   FM   N-FM
Sensitivity
≤ 0.2 µV (12 dB SINAD)
Selectivity
12 kHz @ -6 dB
30 kHz @ -60 dB
Filters
?
Receiver system
Double conversion superheterodyne
IF-frequencies
49.95 MHz / 450 kHz (left band)
38.85 MHz / 450 kHz (right band)
Image rejection
?
Audio output
2W@8Ω for 5% THD

Transmitter

TX-range
136-174 / 400-480 MHz
Modulations
FM   N-FM
RF-output
5 / 10 / 20 / 50 (UHF:40) W

Connections

Antenna
SO-239
Impedance
50Ω
Other
-

Electrical

Power requirements
13.8V DC
Current drain RX
500 mA
TX
8.5 A max

Physical

Dimensions (w×h×d)
140 × 42 × 168 mm (5.51 × 1.65 × 6.61 in) without extrusions
Weight
1,000 gr (2.2 lbs)
Form factor
Mobile
Manufactured
Between 2017 and 20xx

Other features

Usage
Amateur / Ham radio operators
Features + options
-
Accessories
-
RigReference ID
6363
MPN
TYT-TH-007800

Manuals, diagrams and brochures

Tyt TH-7800 User Manual PDF - 895.4 kB, submitted by RigReference

Upload relevant documents

Reviews & stories

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used TYT TH-7800. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the TYT TH-7800 is around:

  • EUR 247.00
  • USD 192.00 ~ USD 199.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2022 USD 199.99 New / Mint Gary Pinson
2018 EUR 259.00 New / Mint RigReference
2018 USD 202.00 New / Mint RigReference
