Radioddity UB15-G

General characteristics

HAM bands

?

Frequency stability

±300 Hz (-30 to +60 °C)

Tuning steps

TX: channelised; RX: 2.5-100 kHz

Memories

50 channels in bank(s)

Receiver

RX-range

161.650-163.275 MHz, 400-470 MHz

Modulations

FM   N-FM

Sensitivity

0.25 µV (12 dB SINAD)

Selectivity

60 dB (adjacent channel)

Filters

?

Receiver system

?

IF-frequencies

?

Image rejection

?

Audio output

1 W

Transmitter

TX-range

462 / 467 MHz (GMRS)

Modulations

FM   N-FM

RF-output

High: 15 W, Low: 5 W

Connections

Antenna

SO-239

Impedance

50Ω

Other

-

Electrical

Power requirements

13.8 V DC

Current drain RX

360 mA

TX

Less than 5 A

Physical

Dimensions (w×h×d)

187 × 53 × 175 mm (7.36 × 2.09 × 6.89 in)

Weight

?

Form factor

Mobile

Manufactured

Between 2026 and 20xx in China

Other features

Usage

General Mobile Radio Service

Features + options

22 GMRS and 8 repeater channels, 50 custom channels
10 NOAA weather channels with alert
Full-keypad control microphone
CTCSS/DCS
RX/TX noise cancelling
Voice recording and playback
VOX
Seven backlight colours

Accessories

-

RigReference ID

6688

MPN

RADIODDITY-UB000015-G

Manuals, diagrams and brochures

No manuals yet for the Radioddity UB15-G. Have a PDF of the user manual, service manual, or schematic? Upload it and help the next operator.



Upload relevant documents

Reviews

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Radioddity UB15-G. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on similar Transceiver equipment, the estimated value of the Radioddity UB15-G is around:

• USD 210 ~ USD 390

This estimate is based on similar equipment and may not reflect the exact value of this model.

These estimates are based on the following prices:
