Related to the Kenwood TR-2200
General characteristics
- HAM bands
- 2m
- Frequency stability
- ?
- Tuning steps
- ?
- Memories
- 6 channels in 1 bank(s)
Receiver
- RX-range
- 144-148 MHz
- Modulations
- FM
- Sensitivity
- ?
- Selectivity
- ?
- Filters
- ?
- Receiver system
- XTAL
- IF-frequencies
- ?
- Image rejection
- ?
- Audio output
- ?
Transmitter
- TX-range
- 144-148 MHz
- Modulations
- FM
- RF-output
- 1 W
Connections
- Antenna
- Built-in sweep
- Impedance
- 50 Ω
- Other
- -
Electrical
- Power requirements
- 13.8V DC
- Current drain RX
- 45 mA
- TX
- 650 mA
Physical
- Dimensions (w×h×d)
- 135 × 58 × 181 mm (5.31 × 2.28 × 7.13 in)
- Weight
- 1.70 kg (3.8 lbs) 10 × NiCd and mic included
- Form factor
- Handheld
- Manufactured
- Between 197x and 197x
Other features
- Usage
- Amateur / Ham radio operators
- Features + options
- -
- Accessories
- -
- RigReference ID
- 2599
- MPN
- DRAKE-TR-000022
Manuals, diagrams and brochures
-
No documents available for this particular model.
- Upload relevant documents
New and second-hand prices
Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Drake TR-22. Just bought or sold this model? Let us know what you traded it for and help other ham operators!
Based on historic data, today's second-hand price of the Drake TR-22 is around:
- USD 0.00 ~ USD 9.00
These estimates are based on the following prices:
