A robustly built, top quality receiver. Optional memory units store frequency only. This model requires a speaker. A highly respected, collectable model.
Accessories: CFL-230 300 Hz Filter, CFL-260 600 Hz Filter, NVA-515 Speaker, CFL-218 1800 Hz Filter, NCM-515 Wired Keypad, NDH-515 24 Channel External Memory, NDH-518 96 Channel External Memory.
The NRD-515 was designed to match the JRC NSD-515D or JRC NSD-515S.
General characteristics
- HAM bands
- 160m 80m 60m 40m 30m (WARC) 20m 17m (WARC) 15m 12m (WARC) 11m (CB) 10m
- Frequency stability
- ± 50Hz per hour after 1 hour.
- Tuning steps
- Continuous
- Memories
- None
Receiver
- RX-range
- 0.1-29.9999 MHz
- Modulations
- AM CW USB LSB RTTY
- Sensitivity
- 0.5 µV 1.6-30 MHz SSB/CW S+N/N=10dB
- Selectivity
- 2.4 / 6 kHz
0.6 kHz optional - Filters
- ?
- Receiver system
- Double conversion superheterodyne
- IF-frequencies
- 1st: 70.455 MHz
2nd: 455 kHz - Image rejection
- > 70 dB (1.6 - 30 MHz)
- Audio output
- 1 W @ 4 Ohms, requires external speaker
Connections
- Antenna
- SO-239
- Impedance
- 50/75Ω
- Other
- -
Electrical
- Power requirements
- Mains
- Current drain RX
- 50W
- TX
- -
Physical
- Dimensions (w×h×d)
- 340 × 140 × 300 mm (13.39 × 5.51 × 11.81 in)
- Weight
- 7.70 kg (17.0 lbs)
- Form factor
- Base Station
- Manufactured
- Between 1979 and 1986 in Japan
Other features
- Usage
- Amateur / Ham radio operators
- Features + options
- ¼" Head. Jack, S-Meter, Attenuator, NB, Mute Terminals, ANL, Line Out Jack, RIT, BFO, AGC, PBT, Speaker Output, MW Tune, Up-Down Tuning, Dial Lock, RF Gain, Int./Ext. VFO Switch.
- Accessories
- -
- RigReference ID
- 3296
- MPN
- JRC-NRD-000515
Manuals, diagrams and brochures
-
No documents available for this particular model.
- Upload relevant documents
New and second-hand prices
Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used JRC NRD-515. Just bought or sold this model? Let us know what you traded it for and help other ham operators!
Based on historic price data, today's estimated value of the JRC NRD-515 in Good condition is around:
- USD 800 ~ USD 1,062
- EUR 444 ~ EUR 467
These estimates are based on the following prices:
