3500 KHz XTAL for adjustment to the amateur bands.

General characteristics

HAM bands
160m  80m  60m  40m  30m (WARC)  20m  17m (WARC)  15m  12m (WARC)  11m (CB)  10m
Frequency stability
?
Tuning steps
Continuous
Memories
None

Receiver

RX-range
0.55-30 MHz in four bands
Modulations
AM   CW   SSB
Sensitivity
AM: 1 µV (10 dB S/N)
SSB: 0.3 µV (10 dB S/N)
Selectivity
4 kHz, shape factor <2
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
Better than 35 dB
Audio output
?

Connections

Antenna
SO-239
Impedance
50Ω
Other
-

Electrical

Power requirements
12V DC or mains
Current drain RX
?
TX
-

Physical

Dimensions (w×h×d)
360 × 160 × 220 mm (14.17 × 6.30 × 8.66 in)
Weight
6.00 kg (13.2 lbs)
Form factor
Base Station
Manufactured
Between 1976 and 197x in Japan

Other features

Usage
Amateur / Ham radio operators
Features + options
Noise limiter, BFO.
Accessories
-
RigReference ID
3574
MPN
MINIX-MR-000073B
