Successor of the Yaesu FRG-7000

General characteristics

HAM bands
?
Frequency stability
300Hz per 30 minutes after warm-up
Tuning steps
?
Memories
12 channels in bank(s)

Receiver

RX-range
0.15-30 MHz
Modulations
AM   N-AM   W-AM   FM   CW   USB   LSB
Sensitivity
0.5 µV 2-30 MHz, SSB/CW (S+N/N=10dB)
Selectivity
AM: 6.0 kHz
SSB/CW: 2.7 kHz
FM: 15 kHz
Filters
?
Receiver system
Double conversion superheterodyne
IF-frequencies
?
Image rejection
?
Audio output
1.5 Watts at 8 Ohms

Connections

Antenna
SO-239 + Clamps / screws
Impedance
50/500Ω
Other
-

Electrical

Power requirements
100/120/220/240V AC 50/60 Hz
Current drain RX
?
TX
-

Physical

Dimensions (w×h×d)
334 × 129 × 225 mm (13.15 × 5.08 × 8.86 in)
Weight
6.00 kg (13.2 lbs)
Form factor
Base Station
Manufactured
Between 1981 and 1984 in Japan

Other features

Usage
Amateur / Ham radio operators
Features + options
Clock / timer
Attenuator
12 optional memory channels
Accessories
-
RigReference ID
4221
MPN
YAESU-FRG-007700

Manuals, diagrams and brochures

Yaesu FRG-7700 Schematic diagram PDF - Unknown size, submitted by RigReference
Yaesu FRG-7700 Survival Guide (by PA0PGA) PDF - Unknown size, submitted by RigReference
Yaesu FRG-7700 Instruction Manual PDF - Unknown size, submitted by RigReference
Yaesu FRG-7700 Service Manual PDF - 19.61 MB, submitted by Gerd

Upload relevant documents

Reviews & stories

Rating Title Submitted
Nice looking. Excellent AM audio quality 10 years ago by dberron
Excellent Receiver 11 years ago by MrBones
Good quality SWL set. 12 years ago by Radio10
my yaesu frg-7700 13 years ago by falconx150
Good fun to listen to 15 years ago by elmer

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Yaesu FRG-7700. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the Yaesu FRG-7700 is around:

  • EUR 8.00 ~ EUR 19.00
  • AUD 35.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2022 EUR 150.00 Used / Good oe3gas
2019 EUR 170.00 New / Okay OE3GAS
2015 EUR 40.00 Used / Fair ON8ODK
2010 AUD 220.00 Used / Mint falconx150
2009 EUR 250.00 Used / Okay dberron
