European model has 1 SO-239 and 1 N-type connector.

General characteristics

HAM bands
160m  80m  40m  30m (WARC)  20m  17m (WARC)  15m  12m (WARC)  6m  10m
Frequency stability
?
Tuning steps
?
Memories
200 channels in 1 bank(s)

Receiver

RX-range
0.1-76 / 108-174 / 420-512 MHz
Modulations
AM   FM   W-FM   CW   SSB
Sensitivity
?
Selectivity
?
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
?
Audio output
?

Transmitter

TX-range
10-160 m + WARC / 6 m / 2 m / 70 cm
Modulations
AM   FM   CW   SSB
RF-output
6-160 m: 100 W, 2 m: 50 W, 70 cm: 20 W

Connections

Antenna
SO-239
Impedance
50 Ω
Other
-

Electrical

Power requirements
13.8V DC
Current drain RX
0.6-1 A
TX
Max 22 A

Physical

Dimensions (w×h×d)
155 × 52 × 233 mm (6.10 × 2.05 × 9.17 in)
Weight
2.10 kg (4.6 lbs)
Form factor
Mobile
Manufactured
Between 2003 and 2004

Other features

Usage
Amateur / Ham radio operators
Features + options
Built-in keyer. Beacon mode. 32 color display. CTCSS. Detachable front panel. DSP option
Accessories
-
RigReference ID
4361
MPN
YAESU-FT-000857

Manuals, diagrams and brochures

No documents available for this particular model.

Upload relevant documents

Reviews & stories

Rating Title Submitted
FT857 11 years ago by hans.geyskens
ft 857 13 years ago by n9utj

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Yaesu FT-857. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the Yaesu FT-857 is around:

  • EUR 299.00 ~ EUR 179.00
  • USD 80.00 ~ USD 429.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2023 EUR 300.00 Used / Good Tom Nilssen
2023 EUR 400.00 Used / Good Carlos Wenzel
2020 USD 450.00 Used / Good Jim M.
2019 USD 850.00 New / Mint KL7SRC
2017 EUR 250.00 Used / Good Augusto
