ICOM IC-732S

General characteristics

HAM bands

160m  80m  40m  30m (WARC)  20m  17m (WARC)  15m  12m (WARC)  10m

Frequency stability

?

Tuning steps

?

Memories

10 channels in 1 bank(s)

Receiver

RX-range

0.5-29.995 MHz

Modulations

AM   FM   CW   SSB

Sensitivity

SSB/CW
1.8-29.995 MHz: 0.16 µV (10 dB S/N)
AM
0.5-1.8 MHz: 13.0 µV (10 dB S/N)
1.8-29.995 MHz: 2.0 µV (10 dB S/N)
FM
28.0-29.7 MHz: 0.5 µV (12 dB SINAD)

Selectivity

SSB/CW: 2.1 kHz (-6 dB), 4.0 kHz (-60 dB)
AM: 6 kHz (-6 dB), 20 kHz (-60 dB)
FM: 12 kHz (-6 dB), 32 kHz (-60 dB)

Filters

?

Receiver system

Triple conversion superheterodyne

IF-frequencies

1st: 69 MHz
2nd: 9 MHz
3rd: 455 kHz

Image rejection

> 70 dB

Audio output

2.6 W @ 8 ohm

Transmitter

TX-range

10-160 m + WARC

Modulations

AM   FM   CW   SSB

RF-output

SSB/CW/FM: 1-10 W, AM: 1-4 W

Connections

Antenna

SO-239

Impedance

50 Ω

Other

-

Electrical

Power requirements

13.8V DC

Current drain RX

4 A

TX

4 A max

Physical

Dimensions (w×h×d)

330 × 111 × 285 mm (12.99 × 4.37 × 11.22 in)

Weight

8.05 kg (17.8 lbs)

Form factor

Base Station

Manufactured

Between 1992 and 199x in Japan

Other features

Usage

Amateur / Ham radio operators

Features + options

-

Accessories

-

RigReference ID

5130

MPN

ICOM-IC-000732S

Manuals, diagrams and brochures

No documents available for this particular model.



Upload relevant documents

Reviews

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used ICOM IC-732S. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on similar Transceiver equipment, the estimated value of the ICOM IC-732S is around:

• USD 215 ~ USD 400

This estimate is based on similar equipment and may not reflect the exact value of this model.
